2024-2025 Funded Projects
Funded Projects for AY 2024-2025
Thanks to our industry and university members, we are currently able to fund four proposed projects for this academic year (August 2024- July 2025). Projects began at the start of the Fall semester, on August 16th, 2024. Congratulations to our PIs for their successful proposals. The ASAP leadership team is expecting to support additional projects as we gather additional support from new members this year.
Project 1: Topological Semimetals by Superconformal CVD
Theme 1 - Electrical and Optical Interconnects
PIs - John Abelson, Gregory Girolami
Supported Students - Laurent Souqui, Tiana Kim Huynh
"In this project, we will address a key challenge in semiconductor technology: to develop the first methods to deposit topological semimetals conformally by CVD or ALD in deep features. The overarching goal is to develop a superconformal chemical vapor deposition route to completely fill interconnect structures with low-resistivity topological semimetals."
Project 2: Photonic Interface for Smart Packaging
Theme 1 - Electrical and Optical Interconnects
PIs - Lynford Goddard, Kent Choquette, Paul Braun
Supported Students - Nikita Duggar, Chloe Armstrong, Dajie Xie
“The overarching project goal is to demonstrate a robust interface of 3-dimensional optical interconnects between 2-dimensional optical source and detector array chips for intra-chip and inter-chip data transfer. We propose to overcome the packaging interface challenge of routing input/output optical signals onto an optoelectronic chip.”
Project 3: Exploring Novel Memory Architecture Using Emerging Devices
Theme 3 - Circuits and Architectures
PIs - Saugata Ghose, Shaloo Rakheja
Supported Students - Arjun Tyagi, Minh S. Q. Truong, Dawei Xiong, Rahul Prabhu, Yiqiu Sun, Ryan Wong, Siyuan Qian
“As the ASAP Center produces new memory devices under Themes 1 and 2, we will explore how to integrate these devices into practical memory architectures that can be fabricated and used at scale. We will develop detailed models of devices being developed by other ASAP projects, and incorporate them into an extended version of our open-source memory architecture simulator, to allow for early-stage (i.e., pre-device-fab) exploration of ideal memory array topologies, architectural properties, and potential for processing-in-memory.”
Project 4: Strain-Induced Mobility Enhancement in 2D Material Transistor
Theme 2 - Heterogeneous Integration
PI - Arend van der Zande
Supported Students - He-Lin (Kevin) Zhao, Yue Zhang
“The goal of this project is to apply process induced strain techniques to enhance transport in 2D field effect transistors. We propose to model how process induced strains from thin film deposition transfer into 2D material monolayers, and leverage process induced strain techniques to enhance mobility in 2D transistors.”
Project 5: Transfer-Printed Single-Crystalline Si Nanomembrane for High- Performance Junctionless MOSFET on BEOL
Theme 2 - Heterogeneous Integration
PI - Qing Cao
Supported Student - Yung Man Yu
“The overarching goal of this project is to realize high-performance, BEOL-compatible CMOS circuits based on transferred-printed ultrathin single-crystalline Si membranes and fully-depleted junctionless transistors. We will develop a process to cultivate high-quality single-crystalline silicon nanomembranes from SOI wafers, and then roll-to-roll transfer them on wafer scale to completed CMOS substrates. Juntionless transistors with optimized structure will be fabricated on these stacked silicon nanomembranes under a restricted thermal budget. They do not require any high-temperature doping step to form p-n junction during fabrication but can offer performance and scalability comparable to FEOL silicon MOSFETs.”
Project 6: Heterogeneous Integration of Lithium Niobate on III-V/Si Substrates
Theme 2 - Heterogeneous Integration
PIs - Minjoo Lawrence (Larry) Lee, Chris Anderson
Supported Students - Cornell Horne, Jason Huang
“Our overarching goal is to create platforms that reimagine photonic device structures to facilitate heterogeneous integration. Thin-film lithium niobate (TFLN), which consists of a bonded layer of lithium niobate on an oxidized silicon substrate, is emerging as a powerful platform for data communication owing to its combination of low propagation loss, strong electro-optic coefficient, and efficient frequency comb generation. Heterogeneous integration of III-V gain with TFLN modulators and frequency combs would enable compact, low-cost optical transceivers for near-term commercial applications in data centers.”
